CUA Load cell for LD3 load cell LD360 load cell to instead of KM load cell for kettle load cell 2klb

CUA  Load cell 2 klb for kettle weighing

FEATURES AND BENEFITS

 Versatile Load Cell for Dry to Wet Applications Due to its low cost and high performance, this load cell is suitable for applications ranging from bulk dry solids to sanitary washdown or corrosive environments.

 Cleanability and Strength Built-in vessel hold-down eliminates mechanical pivot points, a source of bacteria traps and system errors. Less time spent cleaning.

IP68 Submersion Rating, 17-4 ph 900 SS Construction Unsurpassed waterproof protection and corrosion resistance for long life in rigorous CIP wash down and corrosive areas.

 Minimal Deflection Better system performance on tanks with pipes and process plumbing connections versus load cells that need stay rods or check rods.

CUA Compression Load Cell continuously measures the weight of material for in-process and bulk storage vessels.

It is suitable for a wide range of applications from dry, solid material measurement to high-pressure washdown, corrosive or submerged environments and is available in capacities from 1,000 lbs. to 25,000 lbs.

 The design of the CUA keeps the vessel’s center of gravity low and stable.

Vessel tipping, “walking”, or overturning is eliminated, protecting your valuable product.

 Violent agitation is also no match for its integral hold-down design. Installation is simple.

Unlike conventional load cells, no extra external hardware, turnbuckles, or specific cell orientation is needed, even in areas of seismic activity or winds (outdoor vessels).

This lock-down design eliminates the moving pivot points, bearing surfaces and “floating” hardware that can cause long term maintenance and accuracy problems as well as provide a home for bacteria.

Many competitive load cell designs lend themselves to the entrapment of bacteria, requiring extensive cleaning and maintenance. With its smooth surfaces and hermetically sealed design, the CUA requires less cleaning compared to beam or pancake-style load cells.

Its monolithic design eliminates the need for restraints or stay rods and provides options for seismic applications.
